| 产品特性：工业主板 | 品牌：DFI | 型号：PTH961 |
| 设备类型：工控电脑 |
UP to 64GB LPDDR5x- 8533 memory down
8K High Resolution: Supports 8K / 4K resolution
Multiple Displays: 3 DDI, 1 LVDS/eDP
Multiple Expansion: Up to 20 PCIe Lanes
Rich I/O: 1 Intel 2.5GbE, 2 USB 4.0, 4 USB 3.2
系统
处理器
Intel® Core™ Ultra Series 3 Processor Panther Lake
Intel® Core™ Ultra X7 358H (4 P-Cores x 1.9GHz, 8 E-Cores x 1.5GHz, 4 LP E-Cores x 1.5GHz, 18MB cache, 25W)
Intel® Core™ Ultra 5 325 (4 P-Cores x 2.1GHz, 4 LP E-Cores x 1.6GHz, 18MB cache, 25W)
内存
Up to 64GB (optional to 96GB) LPDDR5x-8533 memory down (IBECC supported)
BIOS
AMI BIOS
显示
控制器
Intel® Arc Graphics or Intel® Gr aphics
特性
DX12, Open GL 4.6, Vulkan 1.2
HW Decode: HEVC/VP9/SCC/AV1/AVC
HW Encode: HEVC/VP9/SCC/AVC
显示器
3 x DDI (DDI3 co lay with USB3)
1 x LVDS/eDP
扩充
界面
404/12Xe sku:
Up to 8 x PCIe x1 (Gen4) + 1 x PCIe x4 (Gen5)
484 sku:
Up to 8 x PCIe x1 (Gen4) + 1 x PCIe x8 (Gen5) + 1 x PCIe x4 (Gen5)
1 x I2C
1 x SMBus
1 x eSPI
2 x UART
音讯
音讯编译码器
HD Audio
以太网路
PHY
1 x Intel® I226 series (10/100/1000/2500Mbps), co-lay 1 x PCIe x1 (available upon request)
输入/输出
USB
Up to 2 x USB 4.0 (co-lay with DDI, available upon request)
4 x USB 3.2 Gen.2
8 x USB 2.0
SATA
2 x SATA 3.0 (up to 6Gb/s), co-lay PCIe x1 (available upon request)
DIO
1 x 8-bit DIO
NVMe SSD
1 x 128GB/256GB/512GB/1024GB on board SSD (available upon request)
监视定时器
看门狗定时器
System Reset, Programmable via Software from 1 to 255 Seconds
安全性
信赖平台模块
TPM 2.0
电源
类型
8.5V~20V, 5VSB, VCC_RTC (ATX mode)
8.5V~20V, VCC_RTC (AT mode)
耗能
TBD
支持操作系统
微软
Windows 11 IoT Enterprise 64-bit
Linux
Linux
环境指标
温度
Operating: -40 to 85°C for ET CPU skus, 0 to 60°C,
Storage: -40 to 85°C
湿度
Operating: 10 to 90% RH
Storage: 10 to 90% RH
MTBF
TBD
机械结构
尺寸
COM Express® Basic
125mm (4.92") x 95mm (3.74")
规范
PICMG COM Express® R3.1, Type 6
安规认证
认证
CE, FCC, RoHS
