| 产品特性：工业主板 | 品牌：DFI | 型号：SNA9HE |
| 设备类型：工控电脑 |
AMD EPYC 8004 Processor, up to 64 cores
Up to 6 channels DDR5 4800 RDIMM
1 x Intel® I226 series 10/100/1000/2500Mbps GbE
Multiple Expansion: Up to 79 PCIe Lanes
Rich I/O: 4 USB 3.2, 4 USB 2.0, 2 SATA 3.0
系统
处理器
AMD EPYC™ 8004 Processors
AMD EPYC™ 8534P (64 cores, up to 3.1GHz, 128MB cache, 200W)
AMD EPYC™ 8324P (32 cores, up to 3.0GHz, 128MB cache, 180W)
AMD EPYC™ 8124P (16 cores, up to 3.0GHz, 64MB cache, 125W)
内存
6 channels DDR5-4800 RDIMM up to 576GB (ECC or non-ECC)
扩充
界面
4 x PCIex16, 64 Lanes (Gen 5) + 1 x PCIe x8, 8 Lanes (Gen 5)
6 x PCIex1, 6 Lanes (Gen 3)
1 x PCIex1, Gen3 for BMC
1 x eSPI
2 x I2C
1 x SPI
2 x UART(TX/RX)
1 x SMBus
2 x SmartFAN
以太网路
PHY
1 x Intel® I226 series 10/100/1000/2500Mbps GbE
输入/输出
SATA
2 x SATA 3.0 (up to 6Gb/s)
GPIO
12 x GPIO
Up Side
4 x USB 3.2 Gen 2x1
4 x USB 2.0
监视定时器
看门狗定时器
System Reset, Programmable via Software from 1 to 255 Seconds
安全性
信赖平台模块
TPM 2.0
电源
类型
ATX: Vin, VSB, VCC_RTC
AT: Vin, VCC_RTC
Vin: 12V(+/-5%),VSB: 5V(+/-5%)
耗能
TBD
支持操作系统
微软
Windows Server 2024
Linux
Ubuntu
环境指标
温度
Operating: 0 to 50°C
Storage: -40 to 80°C
湿度
Operating: 5 to 90% RH
Storage: 5 to 90% RH
MTBF
TBD
机械结构
尺寸
COM HPC® Server Size E
160mm (6.30") x 200mm (7.87")
规范
PICMG COM HPC® R1.2, Server Size E
安规认证
认证
CE, FCC Class B, RoHS
